Sievert 8842 Light Line Needlepoint Burner - 8mm
In stock
£22.26
£18.55
SKU
884204
Or 3 Interest-Free Payments of £7.42
Description
Sievert 8842 Light Line Needlepoint Burner – 8mm | 884204 | Gold & Silver Jewellery
The pin-point burner component of the Sievert 3537 Jewellers assembly. Sold here individually for replacement or standalone use with the 3501 Lightline neck tube (350101). M8 × 0.75 threaded connection. 0.25kW, 20g/h at 2 bar. Soft soldering to 400°C, silver soldering to 615°C. The finest flame in the Sievert gas torch system. Requires the 3501 neck tube to connect to a Pro handle — sold separately.
Key Features & Benefits
- Pin-Point Flame — The finest flame available in the Sievert gas torch system for precision jewellery soldering.
- Soft Soldering to 400°C — Suitable for delicate soft soldering applications on precious metals.
- Silver Soldering to 615°C — Full range for gold and silver jewellery and silversmithing work.
- 0.25kW / 20g/h — Very low output and gas consumption for extended precision bench sessions.
- M8 × 0.75 Threaded Connection — Fits the Sievert 3501 Lightline neck tube (350101) only — not direct-fit to standard Pro 86/88 neck tubes.
- Sold Individually — The burner only — the 3501 neck tube is required and sold separately. Also available as the 3537 assembly (8842 + 3501 together).
Ideal For
- Gold, silver & precious metal jewellery soldering
- Silversmithing & goldsmithing bench work
- Replacing a worn 8842 burner in an existing 3537 setup
- Building a Lightline burner configuration on a Pro handle with the 3501 neck tube
The pin-point burner for precision jewellery work — burner only. Order today for fast delivery. The 3501 neck tube (350101) is required to connect this burner to a Pro handle — sold separately. Also available as the complete 3537 assembly (8842 + 3501 together).
Specification
Sievert 8842 Light Line Needlepoint Burner - 8mm Specification
| Brand | Sievert |
|---|---|
| Article Number | 884204 |
| Product Type | Light Line Pin-Point Needlepoint Burner |
| Flame Type | Pin-point – the finest flame in the Sievert system |
| Burner Diameter | 8mm |
| Heat Output | 0.25 kW at 2 bar |
| Working Pressure | 2 bar |
| Gas Consumption | 20 g/h at 2 bar |
| Soft Soldering Capability | Up to 400°C |
| Silver Soldering Capability | Up to 615°C |
| Burner Connection | M8 × 0.75 threaded – fits Sievert 3501 Lightline neck tube only |
| Material | Brass |
| Required Accessory | Sievert 3501 Lightline Neck Tube (350101) – sold separately |
| Also Available | Sievert 3537 – 8842 burner & 3501 neck tube sold together |
| Suitable Applications | Jewellery soldering, gold & silver work, precision metalwork |
Features
Sievert 8842 Light Line Needlepoint Burner - 8mm Features
- Pin-Point Flame — The finest flame available in the Sievert gas torch system for precision jewellery soldering.
- Soft Soldering to 400°C — Suitable for delicate soft soldering applications on precious metals.
- Silver Soldering to 615°C — Full range for gold and silver jewellery and silversmithing work.
- 0.25kW / 20g/h — Very low output and gas consumption for extended precision bench sessions.
- M8 × 0.75 Threaded Connection — Fits the Sievert 3501 Lightline neck tube (350101) only — not direct-fit to standard Pro 86/88 neck tubes.
- Sold Individually — The burner only — the 3501 neck tube is required and sold separately. Also available as the 3537 assembly (8842 + 3501 together).
